ATLS500MA106D

$69.00

The controller has temperature compensation network so that the output current maintains the same even as the controller temperature rises.

In case the controller temperature exceeds a preset limit, 120°C, the controller will be shut down by itself to prevent the controller from being damaged by the over heat.

The output current of the ATLS500MA106 can be set by an input voltage linearly or modulated by an external signal of up to 100kHz in bandwidth, resulting in a minimum 1.5μS rise and fall times at the output current.

DATASHEET

Available on backorder

1~9$69.00 each

10~49$66.00 each

50~199$62.00 each

200~499$59.00 each

>=500$54.00 each

Additional information

Weight 0.3 lbs
