15W Isolated DC-DC Power Module ATMV24V50V300MA1
$99.00
Features:
- Wide Input Power Voltage Range: 18V to 36V
- Output Voltage: 50V
- Max. Output Current: 300mA
- High Efficiency: 78% @VIN = 24V & VOUT =50V & IOUT = 300mA
- Output Ripple Voltage: ≤1% @20MHz
- Isolation Voltage: 1500VDC
- Output Short-Circuit Protection: Automatic Recovery
Full Aluminum Housing for Complete Shielding
Industry Standard DIP Package
- Operating Temperature Range: -40°C to +85°C
100 % Lead (Pb)-free and RoHS Compliant
Applications:
This power module, ATMV24V50V300MA1, is designed for achieving DC-DC conversion from low voltage to high voltage as a power supply source. It is widely used in scientific research and other fields including:
Sustaining Ion Pumps
Spectral Analysis
Electrophoresis
Particle Accelerator
Capillary Electrophoresis
Piezo Devices
Photo Multiplier Tubes
Avalanche Photo Diodes
DESCRIPTION This Power Module is a medium voltage, isolated DC-DC converter with 2:1 input voltage range. With a wide operating temperature range, built in short-circuit protection, providing this unit with high reliability and long life.
Available on backorder
| 1~9 | $99.00 each |
| 10~49 | $94.00 each |
| 50~99 | $89.00 each |
| >=100 | $84.00 each |
Additional information
| Weight | 0.5 lbs |
|---|
