Custom High Voltage Power Supply

Custom High Voltage Power Supply

Need a power supply that standard models can’t cover? Our Custom High Voltage Power Supply (HVPS) service delivers tailor-made solutions optimized for your voltage, current, form factor, control interface, and compliance needs. From rapid prototypes to production, we design for stability, low ripple, safety, and reliability in demanding environments.

What We Customize

Output: 0–100 kV (higher on request), µA to multi-amp ranges, fixed or programmable
Polarity: positive, negative, reversible, floating
Input: AC 100–240 VAC; DC 5–600 VDC; single/3-phase options
Ripple/Noise: ultra-low ripple for imaging & precision instruments
Form Factor: PCB/OEM module, chassis, benchtop, rack-mount
Control & Monitoring: analog (0–5/10 V), potentiometer, RS-232/RS-485, CAN, Ethernet
Protection: OVP, OCP, OTP, short-circuit, arc/flashover detection, soft-start, ramp control
Safety/Compliance: interlocks, shields, creepage/clearance per standards

Design Options

Single or multi-output HV (tracking/independent)
Precision readback (kV/mA), calibration, data logging
Integrated subsystems: filaments, bias supplies, polarity switching
Environmental hardening: extended temperature, vibration, humidity

How We Work

Requirements – voltage/current, load, duty cycle, environment, interfaces, compliance
Proposal – block diagram, key specs, lead time, NRE & unit pricing
Prototype – engineering sample & test report
Validation – iterations to meet performance & safety targets
Production – documentation, serialization, ongoing support

Typical Applications: X-ray/CT imaging, NDT & security screening, semiconductor process & test, E-beam/ion sources, mass spectrometry, PMTs, electro-optics/ESD, plasma & materials processing, scientific instruments.
